Abutment Connection
others
Abutment Connection Type
internal thread
Implant Body Shape
cylinder
Implant Body Features
threaded
Implant Body Thread
buttress
Implant Cervical Shape
wider than body
Implant Cervical Features
polished surface
Implant Apical Features
grooved, round hole
Implant Apical Shape
flat apex
Implant Body Surface
machined/uncoated, HA (hydroxyapatite)
Implant Cervical Features: Polished. Height-2.0mm or 1.0mm.
Platform to Abutment Connection: Internal Thread Diameter-2.5mm. No Anti-rotation. Flat Platform.
Platform Diameter-4.0mm. Internal Lobes- Engage the Mount.
Sizes: Implant Diameter:3.8mm. Implant Length:8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,18.0mm.
Implant Diameter:3.5mm,4.0mm.
Nobel Biocare-Acquired Steri-Oss in 1998.
Platform to Abutment Connection: Internal Thread Diameter-2.5mm. No Anti-rotation. Flat Platform.
Platform Diameter-4.0mm. Internal Lobes- Engage the Mount.
Sizes: Implant Diameter:3.8mm. Implant Length:8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,18.0mm.
Implant Diameter:3.5mm,4.0mm.
Nobel Biocare-Acquired Steri-Oss in 1998.
Implants with Compatible Platforms
