Abutment Connection
internal
Abutment Connection Type
internal hex
Implant Body Shape
cylinder
Implant Body Features
threaded
Implant Body Thread
V-shaped
Implant Cervical Shape
wider than body
Implant Cervical Features
unpolished surface
Implant Apical Features
grooved
Implant Apical Shape
flat apex
Implant Body Surface
sandblast, acid etching
Implant Material
commercially pure titanium (grade 2)
Implant Body Thread: Double Lead Thread.
Implant Cervical Features: Unpolished. Microgroove and Acid Etching.
Platform to Abutment Connection: Internal Hexagon. Hexagon Diameter:2.2mm. Internal Bevel.
Sizes: Implant Diameter:4.5mm.
Implant Length:8.0mm,9.0mm,10.0mm,11.0mm,12.0mm,
13.0mm,14.0mm,15.0mm,16.0mm.
Implant Cervical Features: Unpolished. Microgroove and Acid Etching.
Platform to Abutment Connection: Internal Hexagon. Hexagon Diameter:2.2mm. Internal Bevel.
Sizes: Implant Diameter:4.5mm.
Implant Length:8.0mm,9.0mm,10.0mm,11.0mm,12.0mm,
13.0mm,14.0mm,15.0mm,16.0mm.
