Abutment Connection
internal
Abutment Connection Type
internal hex
Implant Body Shape
tapered
Implant Body Features
threaded
Implant Body Thread
square
Implant Cervical Shape
straight transition from body
Implant Cervical Features
polished surface
Implant Apical Features
grooved
Implant Apical Shape
domed apex
Implant Body Surface
wet shot blasting(aluminium oxide), acid etching
Implant Material
commercially pure titanium (grade 2)
Implant Cervical Features: Polished. 1.0mm.
Platform to Abutment Connection: Internal Hexagon Diameter 2.5mm. Bore Diameter M2.
Sizes:
Platform Diameter:3.75mm. Implant Diameter:3.75mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform Diameter:4.25mm. Implant Diameter:4.25mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform Diameter:5.0mm. Implant Diameter:5.0mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform Diameter:6.0mm. Implant Diameter:6.0mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform to Abutment Connection: Internal Hexagon Diameter 2.5mm. Bore Diameter M2.
Sizes:
Platform Diameter:3.75mm. Implant Diameter:3.75mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform Diameter:4.25mm. Implant Diameter:4.25mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform Diameter:5.0mm. Implant Diameter:5.0mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
Platform Diameter:6.0mm. Implant Diameter:6.0mm.
Implant Length:10.0mm,11.5mm,13.0mm,15.0mm.
