Abutment Connection
internal
Abutment Connection Type
internal hex
Implant Body Shape
tapered
Implant Body Features
threaded
Implant Body Thread
V-shaped
Implant Cervical Shape
narrow, straight transition from body
Implant Cervical Features
polished surface, unpolished surface
Implant Apical Features
grooved
Implant Apical Shape
domed apex
Implant Body Surface
SBM (Soluble Blast Media)
Implant Material
titanium alloy grade 23 (Ti6Al4V-ELI)
Implant Cervical Features: Horizontal Grooves. Micro Threads.
Implant Body Thread: Double Thread.
Platform to Abutment Connection: Internal Hexagon. Platform Diameter 3.5mm.
Internal Thread 1-72 UNF.
Sizes:
Implant Diameter:3.75mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Diameter:4.2mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Diameter:4.7mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Diameter:5.0mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Body Thread: Double Thread.
Platform to Abutment Connection: Internal Hexagon. Platform Diameter 3.5mm.
Internal Thread 1-72 UNF.
Sizes:
Implant Diameter:3.75mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Diameter:4.2mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Diameter:4.7mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implant Diameter:5.0mm.
Implant Length:8.0mm,10.0mm,11.5mm,13.0mm,16.0mm.
Implants with Compatible Platforms
